Rocketry

The rocketry components that you find here are a culmination of years of my experience as an electronics engineer being involved in high power rocketry.  The components that I have developed are used in the design and fabrication of rockets with emphasis on deployment and tracker electronic bays.  The electronic bay components allow for the re-use of bays between rockets and also to allow bays to be reconfigured as technology changes without having to rebuild completely.  At this time, I am releasing a variety of parts for the use in general electronic bays and 54mm coupler tube electronic bays.  There are also a few general purpose "assistants" to make building easier.

You can get an overview of the product line on the Diagrams, How To's & Concepts page which details wiring, assembly, and concepts.

I hope that you find the products of interest and would like to incorporate them into your next rocket.





View as Grid List
Sort by
Display per page

MissileWorks RRC2+ Carrier Kit

ACMWC2P-00174
This is an altimeter carrier for the MissileWorks RRC2+ deployment altimeter.
$2.45

54mm Short Six Inch Bay Kit

BKC-00565
The short bay kit in a complete set of SMT Designs parts that can be assembled into fully functional dual deploy electronics bay (customer supplies coupler tube, altimeter, battery, and PVC pipe ends). Note: a battery holder is an optional part that can be included when ordering.
$20.95

PerfectFlite StratoLoggerCF Carrier Kit

ACPFCF-00173
This is an altimeter carrier for the PerfectFlite StratoLoggerCF dual deployment altimeter.
$2.45

9 Volt Battery Carrier Kit

BYC9V-00177
This is a 9 volt battery carrier.
$2.95

2S 300mAh LiPo Battery Carrier Kit

BYC2S3-00178
This is a 2S 300mAh LiPo battery carrier.
$2.95

Replacement Charge Canister/Shock Cord Tie Plates

SCTP-00186
The Charge Canister/Shock Cord Tie Plates consists of two replacement plates that can be used once the last set is no longer serviceable. These parts are compatible with the Mach1 BT60 bay kits.
$1.50

BT60 CT Bay Template

CTBT-01351
The BT60 CT Bay Template is used to mark holes for 4-40 hardware on a BT60 coupler tube bay.
$1.95

38mm/BT60 BT Bay Template

BTBT-00352
The 38mm/BT60 BT Bay Template is used to mark holes on body tubes to align with a coupler tube bay or other parts.
$3.45

Wiring Assistant

WRAS-00150
This is my version of a third hand that can be used to "assist" you when using SMT Designs' parts.
$2.95

38mm CT Bay Template

CTBT-00351
The 38mm CT Bay Template is used to mark holes and window locations when constructing a coupler tube bay.
$3.45

54mm CT Bay Template

CTBT-00551
The 54mm CT Bay Template is used to mark holes and window locations when constructing a coupler tube bay.
$3.95

54mm BT Bay Template

BTBT-00552
The 54mm BT Bay Template is used to mark holes when constructing a coupler tube bay.
$3.45
