54mm Components

There are just a couple of acronyms that are used in the descriptions, so any references to BT mean Body Tube and CT mean Coupler Tube.  54mm is used as a general term for the basic size rather than an absolute measurement.  The parts here are sized for standard blue tube 2.0 or any similar sized product.  If you have any questions or a special size requirement, please contact SMT Designs on the Contact Us page.  I will adjust diameters of parts for you given your measurements for no charge other than the normal product price (only caveat - non-returnable unless I made them wrong).

The photo shown is an assembly of individual parts for a medium sized dual deploy altimeter bay.  It is meant for a larger rocket than 54mm due to the BT end cap on the left side of the bay.  A completed bay fits in a Coupler Tube (CT) and is held in a Body Tube (BT) by a standard motor retainer.  A completed assembly includes an arming switch accessible through the rocket's wall from the outside, a battery tray, and a sled with a connector for field changes.  O-rings can be used on each end to seal the bay from ejection gases if needed.

Medium Sled Dual Deploy Bay

View as Grid List
Sort by
Display per page

54mm CT 2 Post Deploy Float Bulkhead Kit

BHC2P-00500
The 2 post deploy float bulkhead is designed to be a sealed wall against deployment ejection gases when epoxied in place and allow for two contact connections to an electric match or igniter.
$2.95

54mm CT 4 Post Deploy Float Bulkhead Kit

BHC4P-00521
The 4 post deploy float bulkhead is designed to be a sealed wall against deployment ejection gases when epoxied in place and allow for two contact connections to an electric match or igniter.
$3.45

54mm CT 2 Post Deploy Cap Kit

CC2P-00503
The CT 2 post deploy end cap is designed to be a sealed wall against deployment ejection gases when mounted in place and allow for two outside connections to an electric match or igniter.
$2.95

54mm CT 4 Post Deploy Cap Kit

CC4P-00504
The CT 4 post deploy end cap is designed to be a sealed wall against deployment ejection gases when mounted in place and allow for two outside connections to an electric match or igniter.
$3.45

54mm 2 Post Deploy End Cap Kit

DC2P-00501
The 2 post deploy end cap is designed to be a sealed wall against deployment ejection gases when epoxied in place and allow for four contact connections to electric matches or igniters.
$3.45

54mm 4 Post Deploy End Cap Kit

DC4P-00502
The 4 post deploy end cap is designed to be a sealed wall against deployment ejection gases when epoxied in place and allow for four contact connections to electric matches or igniters.
$3.95

54mm CT Deploy Mounting Ring Kit

DSC-00525
This ring provides three 4-40 threaded inserts for mounting caps and bulkheads which can be for deployment or such things as antenna connections and there are three 6-32 machine screw nuts at 120 degree intervals for mechanically securing the ring inside of a coupler tube if needed.
$2.45

54mm Shock Cord Tie Plate Kit

SKTP-00508
The shock cord tie plate is intended to be used in a minimum diameter rocket to attach the electronics bay to longer shock cords needed for parachutes, nosecone, and fin can.
$2.45

54mm CT Radial Switch End Plate Kit

SWCR-00520
The radial switch end plate was designed to be part of an electronic bay to arm and disarm altimeters using an arming screw through the outside wall of a rocket.
$3.45

54mm CT End Plate Kit

EPC-00523
The end plate kit was designed to provide a sled mounting tab. The end plate can be mounted to any of the other 54mm parts that has SMT Designs' standard ring pattern.
$1.45

54mm CT Connector End Plate Kit

EPCC-00517
The connector end plate kit was designed to provide a tray tab along with a DE9 connector. The end plate can be mounted to any of the other 54mm parts that has SMT Designs' standard ring pattern and will support a battery tray and any of the sleds.
$2.95

54mm CT Wiring Connector End Plate Kit

EPWC-00518
The wiring connector end plate kit was designed to provide a tray tab along with a DE9 connector along with four wiring posts. The end plate can be mounted to any of the other 54mm parts that has SMT Designs' standard ring pattern and will support a battery tray and sled.
$3.45
